Art.No.6507703001 Type: KCB-M12P?/002-KLP2 C

Pagina iniziale BernsteinArt.No.6507703001 Type: KCB-M12P?/002-KLP2 C

Art.No.6507703001 Type: KCB-M12P?/002-KLP2 C Bernstein

qr_logo

Art.No.6507703001 Type: KCB-M12P?/002-KLP2 C

Marca	Bernstein
Prodotto	Art.No.6507703001 Type: KCB-M12P?/002-KLP2 C
Descrizione	Interruttore di prossimità capacitivo
Codice interno	PRT663258
Peso	1
Specifiche tecniche	Rated operating distance Sn 2 mm Mounting flush Standard target 12 x 12 x 1 mm; material: steel; connected to earth Effective operating distance Sr 0,4-2 mm; Sr adjustable with potentiometer (POT); turn right ≙ high sensitivity, turn left ≙ low sensitivity Assured operating distance Sa 0 ≤ Sa ≤ 0,8∙Sr Switching element function N.O. Repeat accuracy R ≤ 0,1∙Sr Differential travel (hysteresis) H ≤ 0,2∙Sr Frequency of operating cycles f ≈ 25 Hz Rate doperational voltage Ue 12 V - 24 V DC Operational voltage range UB 10 V - 36 V DC Rated insulation voltage Ui 75 V DC Rated impulse withstand voltage Uimp 500 V Voltage drop Ud ≤ 1,5 V DC Utilization category DC-13 Rated operational current le 200 mA DC Minimum operational current Im ≥ 1 mA DC Off–state current lr ≤ 0,5 mA DC No–load supply current lo ≤ 15 mA DC Switching element permanent overload and s.c.p. Short–circuit protection pulsed False polarity protection with permutation of +, –, output no damage occurs

La nostra azienda non è un distributore autorizzato. Tutti i diritti sono riservati ai produttori e ai loro partner ufficiali.
