HW01200‐20W02SA3A

Marca	Soldo
Prodotto	HW01200‐20W02SA3A
Descrizione	box finecorsa serie HW
Codice interno	PRT3364033
Peso	0.6
Specifiche tecniche	HW series limit switch box as follows: stainless steel shaft ISO F05 mounting pattern and VDI/VDE3845 shaft independent adjustab, Qty 2 switches / sensors, switch type SPDT electromechanical switches, silver plated contacts, rating 5 Amp @ 125/250 VAC Resistive load, Screw terminal strips with pass through solenoid valve poles, Black RAL9005 polyester powder coating, SOLDO, 2xM20x1.5 cable entries, UV resistant and V0 self extinguish polycarbonate indicator dome 3D red and green flux indicator, Water tight, Ordinary location, Protection level IP67, Ambient temperature range: ‐10°C to 50°C, Aluminum heavy duty body and cover die‐cromated, , 5‐way, 2‐position solenoid valve, single coil, Coil rating: 24VDC 2.3 W, 1/4"NPT female pneumatic connectio
