HP3AD064048SST000MR0000

Marca	ProMinent
Prodotto	HP3AD064048SST000MR0000
Descrizione	Hydraulic motor dosing pump
Codice interno	PRT4518839
Codice doganale	84135040
Specifiche tecniche	modified design with modified membranes calibrated to a flow rate of approx. 45 l/h @ 40 bar at 54 Hz per dosing head -> in total 90 l/h @40 bar at 54 Hz Series: HP3A Hydro Pump 3 Drive type: D - main drive double Pump type: 06404-64 bar, 48 l/h Dispensing head material: SS - stainless steel Seal material: T - standard membrane/PTFE seal. Displacement material: 0 - standard multi-layer membrane Dosing head design: 0 - without vent, without valve spring Hydraulic connection: 0 - standard Version: M - modified Electrical connection (mot: R - rotary - Reg.mot. 4-pin 230/400 V Motor type: 0 - IP55 (standard) ISO class F Stroke sensor: 0 - without stroke sensor Auto Stroke length adjustment: 0 - stroke length adjustment manually Hydraulic oil: 0 - standard Approval: 01 - CE Voltage: 230/400V Frequency: 50/60 Hz Power: 0.75kW Delivery rate: 48/58 l/h Backpressure: 64bar
